Principle of 808nm Diode Laser Hair Removal Machine
Diode laser hair removal technology is based on the selective dynamics of light and heat. The laser goes through the skin surface to reach the root of hair follicle; light can be absorbed and converted into heat damaged hair follicle issue, so that hair loss regeneration without injury surrounding tissue. It provides less pain, easy operation, the safest technology for permanent hair removal now.
Diode laser machine adopts 808 nm, particular effective to hair melanocytes without injury surrounding tissue. The laser light can be absorbed by the melanin in hair follicles, and converted into heat, thus increasing the hair follicle
temperature. When the temperature raises high enough to irreversibly damage the hair follicle structure, the hair will disappear after a period of natural physiological of hair follicles and thus achieve the purpose of permanent hair removal.
Application of 808 Diode Laser
1. Permenent hair removal, better than IPL and E-light; Remove hair on different part of body effectively. Such as armpit hair,
beard, lip hair, hair line, bikini line, body hair and other unwanted hair.
2.Also Relieve symptoms of speckle, telangiectasis, deep color naevus, spider lines, red birthmark and so on.
Features of 808 Diode Laser
1. With Sapphire Crystal on the treatment head that can be used forever without replacement;
2. Powerful semiconductor cooling, air cooling and water cooling can ensure longer working time.
3. Water cycle& water temperature checking system and powerful abstractor extend the service life and safety for the machine;
4. Short treatment time and quick recovery have little effect on patients’ daily work.
5. Advanced flash computer calculater: xenon lamp computer calculater system always show how many flashes you have used.
6. Easier installation: plug-and-play connectors.
7. Minimum energy loss: ceramic silver-gilt lumen refelcts diffuse light onto laser rod to produce stronger power.
Parameter of 808 Diode Laser
1.Laser Type: High Quality 808nm Semiconductor laser beam source
2.Wave Length: 808nm
3.Output: 808nm Treatment of handle out direct output mode (hand gun type)
4.Mode: Single Pulse and Continuous pulse
6.Pulse Width: 10-200 ms(Max.350ms available)
7.Spot Size: 10×12 mm²
8.Energy Density: 0-150J/cm2
9.Electrical Requirement: AC 220V±10% 50Hz; AC 110V±10% 60Hz
10.Cooling System: water cooling + wind cooling + Semiconductor
12.Input Power: 2000W
14.Gross weight: 60KGS
15.Package size: 114*52*54cm
